2019 Malibu Boats M Series M235

2019 Malibu Boats M Series M235
$172,125
Body Style: Ski / Wakeboard
Insurance: Get a free quote
Build & Price View Floorplan

Boat Specifications

  • Identification
    Family Name M Series
    Generic Type (Primary) Ski / Wakeboard
    Manufacturer Country USA
    Major Revision Year 2019
    Revision Status Upgraded
    Competitor Code BOA19SWG0000
    Introduction Year 2016
    IsEmbargoed No
    IsWIP No
    IsPrelim No
    IsCurrent No
    Parent Company Malibu Boats
  • Technical Specifications
    Length (in/mm/ft/m) 281 / 7100 / 23.42 / 7.1
    Length (ft/ft) 23
    Length (ft/in) 5
    Beam (in/m) 102 / 2.6
    Draft (Drive Up) (in/mm) 32 / 812.8
    Draft (Drive Down) (in/mm) 32 / 812.8
    Dry Weight (lbs/kg) 6200 / 2812
    Fuel Capacity (gal/l) 78 / 295
    Number of Passengers 17
    Weight Capacity (lbs/kg) 2397 / 1087
    Performance Standard
    Number Of Fresh Water Holding Tanks 0
    Total Fresh Water Tank Capacity (gal/l) 0 / 0
    Total Gray Water Tank Capacity (gal/l) 0 / 0
    Total Black Water Tank Capacity (gal/l) 0 / 0
    Number Of Water Ballast Tanks 4
    Total Water Ballast Tank Capacity (gal/l) 283 / 1069.7
  • Engine
    Engine Brand Name Monsoon
    Engine Type V8
    Cylinders 8
    Engine Stroke 4-Stroke
    Horsepower (bhp/kW) 510 / 380.6
    Torque (Ft Lbs/Nm) 550 / 745.7
    Cooling Water (Open Loop)
    Valves 16
    Valves Per Cylinder 2
    Valve Configuration OHV
    Bore (mm/in) 103.3 / 4.06
    Stroke (mm/in) 92 / 3.62
    Displacement (l) 6.2
    Compression Ratio 9.1:1
    Starter Electric
    Fuel Requirements Premium
    Fuel Type Gas
    Turbocharged No
    Supercharged Yes
    Engine Model Code 550
    Engine Manufacturer Indmar
    Engine Trim Monsoon 550
    Full Throttle RPM Range Low 5200
    Full Throttle RPM Range High 5400
    Salt Water Capable No
    Engine Alert System Type Visual / Audible
    Emergency RPM Reduction Yes
    Number Of Engines 1
    Engine Configuration Inboard
    Fuel Injector Yes
    Carburetor No
    Carburetion Type Fuel Injected
  • Instrumentation
    Tachometer Standard
    Speedometer Standard
    GPS Standard
    Fuel Level Warning Type Gauge
    Compass Standard
    Depth Indicator Standard
    Water Temperature Gauge Standard
    Air Temperature Gauge Standard
  • Drive Line
    Propulsion Type Propeller
    Propeller Standard
  • Steering
    Outboard Steering Control Remote
    Auto Pilot No
  • Exterior
    Hull Material Fiberglass
    Swim Platform Standard
    Boarding Ladder Standard
    Front Curtain No
    Side Curtains No
    Aft Curtain No
    Aft Sunshade No
    Camper Back No
    Bow Cover No
    Bridge Enclosure No
  • Convenience
    Bilge System Type Automatic Siphon / Electric Pump
    Bilge Pump Alarm Yes
    Engine Compartment Blowers Standard
    Wake Control Standard
  • Topside / Cabin
    Helm Seating Configuration Chair
    Number Of Helm Seats 1
    Helm Roof Type Bimini Top
    Pilot House Door No
    Cockpit Flooring Type Vinyl
    Cockpit Table Yes
    Number Of Cockpit Chairs 0
    Number Of Cockpit Sofas 1
    Number Of Open Bow Seats 4
    Number Of Sofas 0
    Number Of Chairs 0
    Number Of Convertible Beds 0
    Number Of Full Beds 0
    Number Of Single Beds 0
    Total Sleeping Capacity 0
    Number of Queen Beds 0
    Galley Table Configuration No Galley Table
    Convection No
    Number Of Bridge Seats 0
    Number Of Bridge Chairs 0
    Number Of Bridge Sofas 0
    Sun Pad Standard
  • Fishing
    Number of Fishing Pedestal Chairs 0
    Total Baitwell Capacity (gal/l) 0 / 0
    Baitwell Pump No
    Total Fishbox Capacity (gal/l) 0 / 0
    Fishbox Pump No
  • Air Conditioning & Heater
    Cockpit Heater Yes
  • Towing & Hauling
    Trailer Standard
  • Glass
    Walk-Through Windshield Yes
  • Audio & Communication
    Satellite Yes
  • Ski / Wakeboard
    Tow Pylon Standard
    Wakeboard Tower Standard
    Wakeboard Tower Rack Standard
    Wakeboard Tower Lights Standard
    Wakeboard Tower Speakers Standard
  • Fire Suppression System
    Fire Suppression System Standard
  • Storage
    Ski / Wakeboard Storage Standard
  • Lights
    Underwater Lighting Standard
