2013 MasterCraft X Series X2

2013 MasterCraft X Series X2
TBA
Body Style: Ski / Wakeboard
Insurance: Get a free quote
Build & Price View Floorplan

Boat Specifications

  • Identification
    Family Name X-Series
    Generic Type (Primary) Ski / Wakeboard
    Manufacturer Country USA
    Revision Status Carryover
    Competitor Code BOA13SWF0000
    IsEmbargoed No
    IsWIP No
    IsPrelim No
    IsCurrent No
    Parent Company MasterCraft Boat Company, Inc.
  • Technical Specifications
    Length (in/mm/ft/m) 240 / 6100 / 20 / 6.1
    Length (ft/ft) 20
    Length (ft/in) 0
    Beam (in/m) 96 / 2.4
    Draft (Drive Up) (in/mm) 27 / 685.8
    Draft (Drive Down) (in/mm) 27 / 685.8
    Dry Weight (lbs/kg) 3500 / 1587.6
    Fuel Capacity (gal/l) 42 / 159
    Number of Passengers 11
    Weight Capacity (lbs/kg) 1609 / 729.8
    Min Recommended Horsepower (bhp/kW) 320 / 238.8
    Max Recommended Horsepower (bhp/kW) 522 / 389.5
    Total Gray Water Tank Capacity (gal/l) 0 / 0
    Total Black Water Tank Capacity (gal/l) 0 / 0
    Number Of Water Ballast Tanks 3
  • Engine
    Engine Brand Name MV8
    Engine Type V8
    Cylinders 8
    Engine Stroke 4-Stroke
    Horsepower (bhp/kW) 320 / 239
    Horsepower RPM 5000
    Torque (Ft Lbs/Nm) 365 / 494.9
    Torque RPM 4200
    Cooling Water (Open Loop)
    Valves 16
    Valves Per Cylinder 2
    Valve Configuration OHV
    Bore (mm/in) 101.6 / 4
    Stroke (mm/in) 88.39 / 3.48
    Displacement (l) 5.73
    Compression Ratio 9:4:1
    Starter Electric
    Fuel Requirements Regular
    Fuel Type Gas
    Turbocharged No
    Supercharged No
    Engine Model Code MV85.7VDRIVE
    Engine Manufacturer Ilmor
    Engine Trim V-Drive
    Salt Water Capable No
    Engine Alert System Type Visual / Audible
    Emergency RPM Reduction Yes
    Number Of Engines 1
    Engine Configuration Inboard
    Fuel Injector Yes
    Carburetor No
    Carburetion Type Fuel Injected
  • Instrumentation
    Tachometer Standard
    Speedometer Standard
    GPS Standard
    Fuel Level Warning Type Gauge
    Trim Indicator Standard
    Depth Indicator Standard
    Water Temperature Gauge Standard
    Air Temperature Gauge Standard
  • Drive Line
    Propulsion Type Propeller
    Gear Ratio (s) 1:56
    Trim System Type Power
    Twin Propeller No
    Counter Rotating Capable Yes
  • Steering
    Outboard Steering Control Remote
    Auto Pilot No
  • Exterior
    Hull Material Fiberglass
    Swim Platform Standard
  • Convenience
    Bilge System Type Automatic Siphon / Electric Pump
    Engine Compartment Blowers Standard
    Wake Control Standard
  • Topside / Cabin
    Helm Seating Configuration Chair
    Number Of Helm Seats 1
    Helm Roof Type Open Top
    Pilot House Door No
    Cockpit Flooring Type Carpeted
    Number Of Cockpit Sofas 1
    Number Of Open Bow Seats 3
    Number Of Sofas 0
    Number Of Chairs 0
    Number Of Convertible Beds 0
    Number Of Full Beds 0
    Number Of Single Beds 0
    Total Sleeping Capacity 0
    Number of Queen Beds 0
    Galley Table Configuration No Galley Table
    Convection No
    Number Of Bridge Seats 0
    Bridge Carpeting No
    Bridge Table No
    Number Of Bridge Chairs 0
    Number Of Bridge Sofas 0
    Sun Pad Standard
  • Fishing
    Number of Fishing Pedestal Chairs 0
    Total Baitwell Capacity (gal/l) 0 / 0
    Baitwell Pump No
    Total Fishbox Capacity (gal/l) 0 / 0
    Fishbox Pump No
  • Glass
    Walk-Through Windshield Yes
  • Audio & Communication
    Brand Name Clarion
  • Ski / Wakeboard
    Tow Pylon Standard
    Wakeboard Tower Standard
    Wakeboard Tower Rack Standard
  • Fire Suppression System
    Fire Suppression System Standard
  • Storage
    Ski / Wakeboard Storage Standard
