2020 Stingray LR 204

$36,776

Body Style: Bowrider
Insurance: Get a free quote

Build & Price View Floorplan

Boat Specifications

• Identification

  Family Name	LR
  Generic Type (Primary)	Bowrider
  Manufacturer Country	USA
  Revision Status	Carryover
  Competitor Code	BOA20BRF0000
  IsEmbargoed	No
  IsWIP	No
  IsPrelim	No
  IsCurrent	Yes
  Parent Company	Stingray® Boat Company

• Technical Specifications

  Length (in/mm/ft/m)	245 / 6200 / 20.42 / 6.2
  Length (ft/ft)	20
  Length (ft/in)	5
  Beam (in/m)	99 / 2.5
  Bridge Clearance (in/m)	49 / 1.2
  Draft (Drive Up) (in/mm)	18 / 457.2
  Draft (Drive Down) (in/mm)	31 / 787.4
  Deadrise (deg)	20
  Transom Height (mm/in)	635 / 25
  Number Of Pontoons	0
  Dry Weight (lbs/kg)	2490 / 1129.5
  Fuel Capacity (gal/l)	34 / 129
  Number of Passengers	9
  Weight Capacity (lbs/kg)	1715 / 778
  Min Recommended Horsepower (bhp/kW)	115 / 85.8
  Max Recommended Horsepower (bhp/kW)	150 / 111.9
  Total Black Water Tank Capacity (gal/l)	0 / 0
  Number Of Water Ballast Tanks	0
  Total Water Ballast Tank Capacity (gal/l)	0 / 0

• Engine

  Engine Brand Name	DF
  Engine Type	In-line
  Cylinders	4
  Engine Stroke	4-Stroke
  Horsepower (bhp/kW)	115 / 85.8
  Horsepower RPM	5500
  Cooling	Water (Open Loop)
  Valves	16
  Valves Per Cylinder	4
  Valve Configuration	DOHC
  Bore (mm/in)	86 / 3.4
  Stroke (mm/in)	88 / 3.5
  Displacement (l)	2
  Starter	Electric
  Fuel Requirements	Regular
  Fuel Type	Gas
  Turbocharged	No
  Supercharged	No
  Engine Model Code	DF115ATX
  Engine Manufacturer	Suzuki
  Engine Trim	DF115ATX
  Full Throttle RPM Range Low	5600
  Full Throttle RPM Range High	6000
  Engine Dry Weight (lbs/Kg)	405 / 183.7
  Salt Water Capable	Yes
  Engine Alert System Type	Visual
  Emergency RPM Reduction	Yes
  Number Of Engines	1
  Engine Configuration	Outboard
  Fuel Injector	Yes
  Carburetor	No
  Carburetion Type	Fuel Injected

• Instrumentation

  Tachometer	Standard
  Speedometer	Standard
  Fuel Level Warning Type	Gauge
  Trim Indicator	Standard

• Drive Line

  Propulsion Type	Propeller
  Gear Ratio (s)	2.59:1
  Trim System Type	Power
  Twin Propeller	No
  Counter Rotating Capable	Yes

• Steering

  Steering Assist System	Yes
  Outboard Steering Control	Remote

• Exterior

  Hull Material	Fiberglass
  Swim Platform	Standard
  Boarding Ladder	Standard

• Convenience

  Anchor	Standard
  Bilge System Type	Electric Pump

• Topside / Cabin

  Helm Seating Configuration	Chair
  Number Of Helm Seats	1
  Helm Roof Type	Open Top
  Pilot House Door	No
  Cockpit Flooring Type	Fiberglass
  Number Of Cockpit Chairs	1
  Number Of Cockpit Sofas	1
  Number Of Open Bow Seats	2
  Number Of Sofas	0
  Number Of Chairs	0
  Number Of Convertible Beds	0
  Number Of Full Beds	0
  Number Of Single Beds	0
  Total Sleeping Capacity	0
  Number of Queen Beds	0
  Number Of Bridge Chairs	0
  Number Of Bridge Sofas	0
  Sun Pad	Standard

• Fishing

  Number of Fishing Pedestal Chairs	0
  Total Baitwell Capacity (gal/l)	0 / 0
  Baitwell Pump	No
  Total Fishbox Capacity (gal/l)	11 / 42
  Fishbox Pump	No

• Air Conditioning & Heater

  Cockpit Heater	No
  Cabin Heater	No
  Bridge Heater	No

• Towing & Hauling

  Trailer

  Standard

• Glass

  Walk-Through Windshield

  Yes

• Audio & Communication

  Brand Name	Fusion®
  Satellite	No

• Storage

  Ski / Wakeboard Storage

  Standard
